Military B-Series Breakout Mil-Tac Cable 2G62,5/125μ

Article ID
MILTAC-B02G62
Excl. 19% VAT
Delivery time
5-10 working days
Military B-Series Breakout Mil-Tac Cable 2G62,5/125μ
General Characteristics
Impact Resistance 200 Impacts
Crush Resistance 440 N/cm
Flex Resistance 2.000 Cycles
Operating Temperature -55°C to +85°C
Storage Temperature -70°C to +85°C
Specifications
Cabletype Mil-Tac Breakout
Fiber Count 2
Diameter 6.5 mm
Weight 36 kg/km
Installation Tensile Load 2.200 N
Operational Tensile Load 550 N
Minimum Bend Radius Installation 6.5 cm
Minimum Bend Radius Operational 3.3 cm

FO Multimode Fiber OM1 ISO/IEC 11801 62,5/125µ

Type Multimode OM1 ISO/IEC 11801
Core diameter

62.5 µm

Cladding diameter

125 µm

Numeric aperture

0.275
Wavelength 850/1310 nm

Gigabit Ethernet

275/550 m

10-Gigabit Ethernet

33/300 m (1310 CWDM lasers (10GBASE-LX4))

Maximum cabled attenuation

3.5/1.5 dB/km

Minimum Laser EMB bandwidth

200/500 MHz-km

Minimum OFL LED bandwidth

200/500 MHz-km


More Information
Delivery time 5-10 working days
Manufacturer tde
Systems tde - Mil-Tac Cable
Category FO Cables
Mediaobjects
Cable color Schwarz
Fiber type 62,5/125 µm OM1
Number of fibers 2
