24VDC, 10 Watts – DIN Rail Mount

Power Output

• Voltage: 24VDC
• Current Rating: .42A
• Power Rating: 10 Watts
• Ripple & Noise Max: 150mVp-p
• Voltage Tolerance: ±2.0%
• Line Regulation: ±1.0%
• Load Regulation: ±2.0%
• Setup, Rise Time: 1000ms, 30ms
• Hold Up Time: 25ms/115VAC

Power Input

• Voltage Range: 85~264VAC, 120~370VDC
• Frequency Range: 47~63Hz
• Efficiency: 84%
• AC Current (Typical): [email protected]
• [email protected]
• Inrush Current (Cold): [email protected]
• [email protected]
• Leakage Current: <[email protected]

Protection

• Overload: 105% Rated Output
• Overvoltage: 27.6~32.4V

Dimensions

• Width: 0.89” [22.5 mm]
• Depth: 3.94” [100 mm]
• Height: 3.54” [90 mm]

Environment

• Operating: -20°C to 70°C
• Storage: -40°C to 85°C
• Humidity: 20% to 90% (non-condensing)

Weight

• 0.37 lbs. [0.17 kg]

MTBF

• 584Khrs

Certifications

• Safety: UL508, TUV EN60950-1, NEC Class 2/LPS
• EMC Emissions: EN55011, EN55022, CISPR22, EN61204-3 Class B, EN61000-3-2, EN61000-3-3
• EMC Immunity: EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11, EN55024, EN61000-6-1, EN61204-3 A IEC60068-2-6 (Vibration)

Warranty

• Lifetime
